2,8 colio 240*320 Plačiosios temperatūros TFT modulis

Šis „Victronix 2,8 colio 240“*320 Plačiosios temperatūros TFT modulis yra pramoninio lygio 2,8 colio TFT LCD modulis, sukurtas siekiant užtikrinti patikimą našumą reikalaujančiomis sąlygomis. „Victronix 2.8inch TFT“ modulis sujungia 240 × 320 pikselių skiriamosios gebos ekraną su 262K spalvomis, jis užtikrina, kad traškūs vaizdai būtų optimizuoti 6 valandos peržiūros kampui. Kaip profesionalus TFT modulių gamintojas ir tiekėjas Kinijoje, „Victronix“ teikia RGB/MCU/SPI sąsajas, kad patenkintų įvairaus klientų poreikius.

Modelis:VXT280GQSW-01

Siųsti užklausą PDF parsisiųsti

Prekės aprašymas

In the age of intelligence, TFT MODULE helps us to present the required data in the form of images. The quality of the TFT module has a critical impact on its application. What are the advantages of the Victronix 2.8 inch 240*320 Wide Temperature TFT Module? At first, its wide temperature range from -30°C to 80°C makes it more suitable for harsh industrial and outdoor settings. Secondly, it has a high brightness of 350 cd/m², and its backlight lifetime is also for up to 30,000 to 50,000 hours, ensuring that it can be used for clarity and hours of use in different lighting situations. Besides, this 2.8inch TFT module has an active area of 43.20×57.60mm and outline dimensions of 50.00×69.20×2.7mm, RoHS-compliant, and shock-resistant.

This Victronix 2.8inch TFT module is widely used in HMIs, control panels, machinery displays, automotive dashboards, fleet monitoring systems, portable diagnostic tools, patient monitors, solar inverters, smart grid interfaces, and rugged IoT hubs.

Applications:

· Industrial controls, medical devices, automotive dashboards, portable instruments, or embedded systems requiring reliability in extreme temperatures.

General Specifications

Item	Contents	Unit	Note
LCD Type	TFT	-
Display color	262K
Viewing Direction	6	O'Clock
Gray scale inversion direction	12	O'Clock
Operating temperature	-30~+80	℃
Storage temperature	-30~+80	℃
Module size	2.8	inch
Active Area(W×H)	43.20x57.60	mm
Number of Dots	240*320	dots
Controller	ST7789V	-
Power Supply Voltage	3.3	V
Outline Dimensions	50.00x69.20x2.7	mm
Backlight	4X1-LEDs(white)	pcs
Weight	---	g
Interface	RGB/MCU/SPI	-
